GANTRY

Automated Stone Saws

Rail guided design to size different block

dimensions as well as rip finished stone.

AVAILABLE SIZES

3’ GANTRY

Specifications:

  • Pulley-Enhanced 20-Horsepower Motor

  • 8" Blade Collars

  • 13" Max Depth of Cut

  • Holds 24" - 36" Diamond Tipped Blade

  • Standard Dimensions 8' High x 20' Long x 8' Deep

    *The picture shown has an optional manual turn table

5’ - 6’ GANTRY

Specifications:

  • Pulley-Enhanced 25 Horsepower Motor

  • 10" Blade Collars

  • 23" - 29" Max Depth of Cut

  • Holds 42" - 72" Diamond Tipped Blade

  • Standard Dimensions 11' High x 20' Long x 8' Deep

7’-6” - 8’-9” GANTRY

Specifications:

  • Pulley-Enhanced 40 Horsepower Motor

  • 12" Blade Collars

  • 37" - 43" Max Depth of Cut

  • Holds 60" - 100" Diamond Tipped Blade

  • Standard Dimensions 12' High x 20' Long x 9' Deep

10’ - 11” - 6” GANTRY

Specifications:

  • Pulley-Enhanced 50-60 Horsepower Motor

  • 18" Blade Collars

  • 50" - 60" Max Depth of Cut

  • Holds 120" - 138" Diamond Tipped Blade

  • Standard Dimensions 18' High x 24' Long x 9' Deep

We specialize in customizing our products to fit the unique needs of our clients.

Whether you need longer runs to increase loading capacity or multi-blade options for exponential increases in production...

if you can dream it, we can build it!
